Automated guided vehicle L600 and L1200

The automated guided vehicle (AGV) L600 and L1200 is primarily used in closed areas without people traffic. It picks up goods carriers and transports them to a multifunctional workplace.

Due to the low construction height almost all types of load carriers can be combined with the vehicle. Storage space can be used to the maximum at the bottom. The maximum lifting weight of 600 or 1,200 kg leaves plenty of room for loading the carriers. With a speed of up to 1.5 m/s, the AGV is slightly faster than a person with average walking pace. With five hours travel time per 30 minutes charging time, the built-in lithium-ion battery technology allows for high availability.

Dimensions

967 x 750 x 340 (L/W/H) in mm

Payload

up to 600 or 1,200 kg

Speed

up to 1.5 m/s

Safety

in closed areas without people traffic with wireless emergency stop

Navigation

Grid based (optical localization of markers with Data Matrix Codes)

Travel / charging time

80 - 15 % SOC with 500 / 1,000 kg load approx. 5 h / 15 - 80 % SOC approx. 30 min.
